Operating Instructions Cerabar M PMP41 Deltabar M Deltapilot M
Applications
The Cerabar M transmitters measure the gauge and absolute pressure of gases, vapours, liquids and dusts and can be used in all areas of process engineering. The modular design of the Cerabar M enables it to be used in all industrial environments.
Features and Benefits
• Accuracy
− Linearity better than 0.2% of set span
− Adjustable measuring range with TD 10:1
− Long-term stability better than 0.1%
• Sensors
− Dry capacitive ceramic sensor up to 40 bar (600 psi)
– corrosion and abrasion resistant with high overload protection and vacuum-tightness − Piezoresistive metal sensor for measuring ranges up to 400 bar (6000 psi)
• Electronics
− Analogue: low-cost and accurate with short response time especially for rapid processes
− Smart: intelligent with versatile operating procedures via HART protocol
− PROFIBUS-PA: tried and tested for digital communications
• Housings
With its stainless steel housing without dead volume, the Cerabar M fulfils all the special hygienic requirements of the food and pharmaceutical industries. The polyester-epoxy coated aluminium housing has been field-proven in the process industry.
• Process connections
All customary thread versions, hygienic connections and flanges are available.
